Bidirectional glass fiber warp knitting geogrid

PRODUCT DETAILS

DESCRIPTION:

Made from GE fiber by weaving technology and coating treatment.

Specification: 30-30,50-50,80-80,100-100,120-120kN

Property:

1.High strength, low elongation
2.Heat-resistant,high modulus
3.Light weight, good flexibility
4.Anti-erosion,long lifetime

Production Standard: JC 893.1-1998

APPLICATION:

Used in foundation engineering, road, mine protection. Coastal dike slope protection engineering foundation reinforcement treatment. Increasing the load. For coal mine roadway, bolting and concreting roadway supporting (guard net, top net).

The bidirectional glass fiber warp knitting geogrid technical indicators(JT/T480-2002)
Item	Size	GSB25-25	GSB30-30	GSB40-40	GSB50-50	GSB80-80	GSB100-100	GSB125-125	GSB150-
									150

Tensile Strength KN/m	Logitudinal	≥25	≥30	≥40	≥50	≥80	≥100	≥125	≥150

	Traverse	≥25	≥30	≥40	≥50	≥80	≥100	≥125	≥150
Elongation Rate％		≤4	≤4	≤4	≤4	≤4	≤4	≤4	≤4
Temperature		-380	-380	-380	-380	-380	-380	-380	-380
Resistance℃
Note:The above table is referring to JT/T480-2002 standard, special sizes are available at customer's request.
